Sort up to 24,000 Letters and 18,000 Flats Per Hour
The NPI Vsort is revolutionizing flat-sorting technology with an industry leading throughput of 24,000 letters and 18,000 flats per hour. Equipped with patented anti-jam technology and remarkable speed, it effectively reduces the necessity for human intervention. This results in significant cost savings and improved profits. The Vsort boasts impressive throughput capabilities and processes letters and flats up to 0.6 inches thick.
Featuring a modular design, the Vsort was created with your future growth in mind. The modular design gives you the ability to add more chutes and/or pockets when needed.
At the end of the day, what you really care about is your bottom line — and that’s where Vsort really shines.
Revolutionizing Flat Sorting Technology
Up to 24,000 Letters & 18,000 Flats Per Hour | Compact and Scalable Design | Reduce Labor Requirements
An Unmatched and Easy to Use Flat Sorting System
High Throughputs of Letters and Flats
Throughputs up to 24,000 Letters and 18,000 Flats Per Hour
Top Performing Multi-Line Optical Character Reader (MLOCR)
With text and handwritten capabilities
Omni-Directional Software-Based Barcode Reader
Processes IMB, two-dimensional and linear barcodes
Processes Flats up to 0.6” Thick
Reliably processes thicker flats
Advanced Sweep-Less Chute Design
User-Friendly Diagnostic Tools
View the statistics of your sorting operations
Sorter Pocket Design Leverages Patented Anti-Jam Technology
For more reliable processing
Flexible Stacker Design
Allows for pockets, chutes or a combination of both
Transmission-Free, Direct-Drive System
Reduces power consumption, downtime, and decibel level
Optional Integrated Conveyor
Reduces labor requirements
Modular Design
Provides the ability to accommodate future growth by adding more chutes and/or pockets
New Optesuite Postal and Analytics Software Package
Software required to process mail for USPS
Configured for Incoming and Outgoing Mail Operations
A versatile letter and flats sorting solution
Physical Mail Characteristics
| LENGTH | Min 5″ (127 mm) / Max 13″ for mixed (330 mm) Max 15″ for flats (381 mm) |
| HEIGHT | Min 3.5″ (88.9 mm) / Max 11.75″ (254 mm) |
| THICKNESS | Min 0.007″ (.178 mm) / Max .5″ (12.7 mm) |
Power Requirements
| VOLTAGE | 208 VAC 3 phase Wye configuration |
| CURRENT | 30 – 90 Amps per phase |
| FREQUENCY | 60 Hz |
| – or – | |
| VOLTAGE | 415 VAC 3 phase Wye configuration |
| CURRENT | 15 – 45 Amps per phase |
| FREQUENCY | 50 Hz |
Equipment
| MAGAZINE | Standard capacity: 55″ (1409.7 mm) |
| READER TRANSPORT UNIT | Mounting provisions for Reader Camera; Section to level the mail to transport deck |
| PICK-OFF RATE | Letter: Up to 24,000 mailpieces per hour; Flats: Up to 18,000 mailpieces per hour |
| DELAY MODULE | Latency section of OCR and Address Lookup |
| INKJET/BARCODE READER* | Inkjet and Barcode Reader/Verifier; Transport Section |
| 12 POCKET STACKER MODULE | Pocket capacity: 15″ (381mm) of mail per bin |
Optional Equipment
| 12 Pocket Chute Module(s) |
| 12 Pocket Mixed Module |
| Conveyor System |
Operating Environment
| FLOOR LANDING | 33 lbs/sq. inch (2.3kg/sq. cm) |
| TEMPERATURE | 50° F (10° C) to 104° F (40° C) |
| RELATIVE HUMIDITY | Up to 95% non-condensing |
Series | Level(s) | Side(s) | Mail Size |
|---|---|---|---|
| Flats | 1 | 1 or 2 | *B |
| Mixed | 1 | 1 or 2 | *C |
Mail Size Reference
A | B | C | |
|---|---|---|---|
| Maximum Thickness | 1/4″ (6.35 mm) | 1/2″ (12.7 mm) | 3/8″ (9.5 mm) |
| Maximum Length | 11 1/2″ (292.1 mm) | 15″ (381 mm) | 13″ (330 mm) |
| Maximum Height | 6 3/8″ (162.1 mm) | 12″ (304.8 mm) | 12″ (304.8 mm) |
